LED Cob Display

LED Cob Display

Pixel pitch:0.93/1.25/1.56mm
Module size:150x168.75mm
300x168.75mm
Cabinet size:600x337.5x32.4mm
Brightness:600nit
Refresh Frequency:≥3840HZ

Main feature

Semiconductor
Process
Micro LED integrated
architecture
Cold screen
Anti-Glare
Accurate color
expression
Ultra high
ink consistency

Ultra-light and ultra-thin

Made of die-cast aluminum, it significantly reduces weight and is easy to handle and install. Slim and light in shape, it saves space and has lower transportation costs.

Aviation grade aluminum die-casting

Aviation grade aluminum die-casting process, selecting high-quality aluminum with high strength and lightweight weight, and high screen flatness

Low Consumption Cold Screen

XGL Semiconductor also adopts a common cathode architec-
ture,which can accurately distribute voltage and current to red
and blue light chips,thereby significantly reducing power
consumption and reducing on-resistance,thereby bringing
about a lower screen temperature.

Coral dimension
Coral dimension

Parameters

  • Title
  • led Types
  • Module resolution
  • Module size
  • Cabinet size
  • Cabinet resolution
  • Cabinet weight
  • Installation method
  • Point density (dot/m ²)
  • Brightness (Nits)
  • Viewing Angle(H/V)
  • Maximum contrast
  • Signal color processing bit
  • Scanning
  • Refresh rate
  • Frame change frequency
  • Color temperature
  • Working voltage
  • Peak power
  • Average power
  • Continuous working time
  • 0.93
  • COBIntegrated lamp drive
  • 160x180
  • 150x168.75
  • 640x360
  • 600*337.5*32.4mm
  • 4.3Kg/Cabinet
  • Hoisting/mounting/wall hanging
  • 1137422
  • 600 nit
  • H160/W160°
  • ≥10000:1
  • 13bit
  • 54
  • 3840
  • 60Hz
  • 3000-18000 K Tunab1e
  • AC:100V-240W(50-60Hz)
  • 350m/m²
  • 160W/m²
  • ≥7x24hrs
  • 1.25
  • COBIntegrated lamp drive
  • 240x135
  • 150x168.75
  • 480x270
  • 600*337.5*32.4mm
  • 4.3Kg/Cabinet
  • Hoisting/mounting/wall hanging
  • 640000
  • 600 nit
  • H160/W160°
  • ≥10000:1
  • 13bit
  • 60
  • 3840
  • 60Hz
  • 3000-18000 K Tunab1e
  • AC:100V-240W(50-60Hz)
  • 350m/m²
  • 160W/m²
  • ≥7x24hrs
  • 1.56
  • COBIntegrated lamp drive
  • 192x108
  • 300x168.75
  • 480x270
  • 600*337.5*32.4mm
  • 4.3Kg/Cabinet
  • Hoisting/mounting/wall hanging
  • 409600
  • 600 nit
  • H160/W160°
  • ≥10000:1
  • 13bit
  • 54
  • ≥3840
  • 60Hz
  • 3000-18000 K Tunab1e
  • AC:100V-240W(50-60Hz)
  • 330m/m²
  • 170W/m²
  • ≥7x24hrs
